TPO Roofing Membrane

tpo specs and documents

Not all TPO is built like IB TPO

• Performance: Meets and exceeds ASTM D 6878-21, for Thermoplastic Polyolefin (TPO) Membrane and higher than average thickness over scrim per (D7635)

• Contractor Friendly: Wide welding window for easier installation providing a good range of speeds and temperatures during installation.

• Climate Resilience: Excellent flexibility, highly reflective which helps reduce heat absorption and lowers energy costs. Excellent UV resistance and ozone resistance.

• Energy Benefits: Cool Roof Rating (CRRC), compliant with California Title 24 requirements for Solar Reflectance and Emissivity, and LEED (SRI) for (White, Tan)

• Made in USA: IB TPO SM Membranes are manufactured in the USA with globally sourced materials.

Available Colors: White Gray* Tan* *Gray and tan are special order only Approvals: CRRC COOL ROOF RATING COUNCIL ® FM APPROVED c UL us LISTED

LONGEST

INDUSTRY WARRANTY

High-Quality TPO Membranes

IB TPO features a weft-inserted polyester scrim and meets all requirements of ASTM D6878. Our offering includes: 60 mil — available in 3 colors, and 80 mil — available in 3 colors, with both Smooth and Fleece Back options.

Packaging Specifications

Packaging Specifications

Membrane Dimensions Roll (Sq. Ft.) Rolls / Pallet Approx. Pallet Weight
60 Mil 5' × 100' 500 sq. ft. 8 1,424 lbs.
6' × 100' 600 sq. ft. 8 1,728 lbs.
8' × 100' 800 sq. ft. 8 2,320 lbs.
10' × 100' 1,000 sq. ft. 8 2,856 lbs.
12' × 100' 1,200 sq. ft. 8 3,440 lbs.
80 Mil 5' × 100' 500 sq. ft. 4 980 lbs.
6' × 100' 600 sq. ft. 4 1,188 lbs.
8' × 100' 800 sq. ft. 4 1,572 lbs.
10' × 100' 1,000 sq. ft. 4 1,964 lbs.
12' × 100' 1,200 sq. ft. 4 2,392 lbs.
All weights are approximate. Dimensions listed as Width × Length.

IB TPO SM membranes work for new roofs, recoveries, and reroofs as the main field membrane and for roof-to-wall flashings. They can be adhered, induction welded, or mechanically fastened to a prepared substrate with approved fasteners, plates, or adhesive. Seams are heat-welded with hot-air tools.

Illustration of a modern hospital complex with multiple white buildings, surrounded by green trees, and a taller office building in the background. The scene is viewed from above, with clear skies.
Graphic showing two warranty badges. The first badge reads "30 Year Commercial Warranty" with the IB logo. The second badge reads "Lifetime Residential Material Warranty" with the IB logo.
Logo of IB Roof Systems, a company specializing in PVC and fluid-applied roofing solutions.
